The Xiaomi TV Max 86" 4K UHD Smart TV is designed to deliver an immersive home entertainment experience through its ultra-large 86-inch display and cinematic picture technologies. A near bezel-less design combined with a high screen-to-body ratio allows a wider viewing area to be enjoyed, while the 4K Ultra HD resolution ensures that every scene is displayed with exceptional clarity and detail. With support for Dolby Vision IQ, HDR10+, and a wide DCI-P3 color gamut, rich colors and enhanced contrast are presented to reproduce visuals as intended by filmmakers.

Smooth motion and responsive performance are provided through the 120Hz refresh rate and 4K 120Hz MEMC technology, where frame interpolation is applied to minimize motion blur and stuttering in fast-moving scenes. Whether high-speed sports, action films, or competitive gaming are being viewed, fluid visuals and sharp image transitions are maintained. A powerful quad-core processor and ample memory are integrated to ensure fast processing and seamless multitasking while streaming or running applications.

Key Features

Ultra-Large 86-Inch Cinematic Display
A massive 86-inch display is featured to provide a theatre-like viewing environment in the comfort of home. The near bezel-less design and expansive viewing angles allow the screen to remain visible from multiple seating positions, making it suitable for large living spaces and group entertainment.

120Hz Refresh Rate with 4K 120Hz MEMC
Smooth motion performance is achieved through the ultra-high 120Hz refresh rate combined with MEMC (Motion Estimation and Motion Compensation). High-speed scenes are processed through frame interpolation to reduce motion blur and stutter, ensuring clearer playback during sports broadcasts, action sequences, and gaming sessions.

Full-Array Local Dimming for Enhanced Contrast
A full-array local dimming backlighting system is implemented with multiple lighting zones. Greater control of brightness and shadow levels is achieved, allowing deeper blacks and brighter highlights to be produced for more dynamic and layered visuals.

Cinema-Level Color with DCI-P3 and 1.07 Billion Colors
Accurate color reproduction is delivered through the DCI-P3 wide color gamut, covering up to 90% of the spectrum. With support for 1.07 billion colors, smoother color gradients are displayed, ensuring film scenes appear natural and detailed.

Dolby Vision IQ Smart HDR Technology
Dolby Vision IQ dynamically adjusts HDR settings according to ambient lighting conditions. Visual details remain balanced regardless of the room’s brightness, allowing consistent picture quality throughout the day.

Dolby Atmos and DTS:X Immersive Audio
The integrated speaker system with four drivers produces powerful and detailed sound. Support for Dolby Atmos and DTS:X introduces three-dimensional audio effects, creating an immersive environment where sound can be perceived from multiple directions.

HDMI 2.1 for Advanced Gaming
The HDMI 2.1 port allows 4K 120Hz video transmission from modern gaming consoles. Low latency and high-speed response enable smoother gameplay, making the television suitable for competitive gaming experiences.

Android TV 11 Smart Entertainment Platform
Android TV 11 provides access to a large ecosystem of entertainment content. Thousands of applications, games, and streaming services are supported through the Google Play Store, while popular platforms such as Netflix, Prime Video, and YouTube can be accessed directly.

Wi-Fi 6 for Faster Connectivity
Next-generation Wi-Fi 6 technology is supported to improve network efficiency and bandwidth. Faster streaming speeds and more stable wireless connections are achieved, particularly in busy network environments.

Smart Voice Control with Google Assistant
Hands-free control is enabled through Google Assistant, allowing voice commands to be used for searching content, checking information, or managing compatible smart home devices from a distance.

Specifications

Display

• Display Type: 4K UHD

• Resolution: 3,840 × 2,160

• Color Gamut: DCI-P3 90% (typ)

• Color Depth: 1.07 billion (8-Bit + FRC)

• Refresh Rate: 120Hz

• MEMC: 4K 120Hz

• Viewing Angle: 178°(H) / 178°(V)

HDR

• Dolby Vision IQ: Yes

• HDR10+: Yes

• HLG: Yes

Speaker

• Sound Output: 15W + 15W

• Audio Support: Dolby Atmos | DTS®:X

System

• Operating System: Android TV™ 11

Platform

• Processor: MediaTek MT9617

• CPU: Quad A73

• GPU: Mali G52MC1

Smart Home

• Far-field Google Assistant

• Smart Home Control Hub

• Chromecast Built-in

• Supports Miracast

Design

• Screen Size: 86"

• Display Style: Limitless display with no-bezel

• Color: Grey

• Stand Type: Double

• Frame Material: Metal

• Stand Material: Metal

Dimensions

• Dimensions Including Base (L × W × H): 1924.04 × 441.42 × 1181.94 mm

• Dimensions Without Base (L × W × H): 1924.04 × 91.32 × 1102.16 mm

• Packing Size (L × W × H): 2080 × 220 × 1280 mm

Weight

• Weight Including Base: 44.5 kg

• Weight Without Base: 43.6 kg

• Packing Weight: 56.3 kg

Wall Mount

• Wall Mount Size: 600 × 400 mm

Connectivity

• Bluetooth: Bluetooth 5.0

• Wi-Fi: Wi-Fi 6, 2.4GHz / 5GHz

• HDMI: 2.0, 2.1, CEC

• USB: 2.0 × 2

• Composite In (AV): Yes

• CI Slot: Yes*

• Ethernet (LAN): Yes

• Optical Digital Audio Out: Yes

• 3.5mm Headphone Jack: Yes

• Broadcasting System: DVB-T2/C, DVB-S2*

Power

• Power Consumption: 450W

• Voltage: 100-240V ~ 50/60Hz

Operating Environment

• Operating Temperature: 0℃ – 45℃

• Operating Humidity: 20% – 80%

• Storage Temperature: −15℃ – 45℃

• Storage Humidity: <80%

Accessories

• 360° Bluetooth Remote Control ×1

• Screws Bag ×1

• Stands ×2

• Power Cable ×1

• User Manual ×1

• Warranty Card ×1

Conclusion
The Xiaomi TV Max 86" 4K UHD Smart TV is engineered to provide large-scale cinematic visuals, smooth high-refresh motion, and immersive audio performance within a modern smart TV platform. Advanced picture technologies, high-speed connectivity, and Android TV functionality are integrated to deliver versatile entertainment, gaming, and streaming capabilities for large home viewing environments.
