Power and network expansion is enabled by the Tenda TEF1110P-8-63W switch, designed to support multiple PoE+ devices such as security cameras, wireless access points, and VoIP phones. Eight of its ten Fast Ethernet ports supply PoE power following IEEE 802.3af/at standards, while the two remaining ports function as non-PoE uplinks for connecting to a router or other switches. Unmanaged functionality speeds installation, so plug-and-play deployment is achieved without configuration.
Durability and convenience are combined in this unit’s design. A metal housing is used to provide protection and help dissipate heat, and a total 63 W PoE power budget ensures powered devices receive consistent power. Surge protection is built in to safeguard against power spikes, and both desktop and wall-mount options are supported to suit varied installation scenarios. Link/activity LEDs on each port allow status monitoring, while Auto-MDI/MDIX simplifies cabling needs by eliminating crossover cable concerns.
Key Features and Explanations
Eight PoE+ Output Ports: Most connected devices may receive both data and power from the switch without necessitating separate power injectors.
Two Uplink-Only Ports: Dedicated for data-only connections, preventing PoE draw and enabling connection to routers or higher-level switches.
High Power Budget (63 W): Enough power is provided to serve several PoE+ devices simultaneously under typical load conditions.
Metal Housing & Surge Protection: Physical enclosure adds robustness; protection helps resist damage from voltage spikes or electrical storms.
Auto-MDI/MDIX on All Ports: Proper cable type is automatically detected, simplifying cabling deployment in diverse setups.
Unmanaged & Plug-and-Play: No configuration is required; basic network expansion is completed once device is connected and powered.
Specifications
Ports: 10 × 10/100 Mbps RJ-45 ports (8 PoE+/PoE out + 2 uplink only)
PoE Standards: IEEE 802.3af/at supported on the PoE output ports
Total PoE Budget: 63 W for all PoE ports combined
Switching Capacity: Full forwarding at 10/100 Mbps for all ports simultaneously
MAC Address Table Size: Approx. 1,000 entries
Surge Protection: Built-in protection for power input and Ethernet ports
Housing: Metal shell; desktop or wall-mount form
LEDs: Link/Activity indicators per port; Power LED indicator
Auto Features: Auto-negotiation; Auto-MDI/MDIX on all ports
Operating Temperature: ~0 °C to +40 °C
Storage Temperature: ~-40 °C to +70 °C
Operating Humidity: 10%-90% RH non-condensing
Storage Humidity: 5%-90% RH non-condensing
Conclusion
An effective solution for powering multiple PoE devices in small offices, retail environments, or surveillance systems is provided by the Tenda TEF1110P-8-63W. Dependable power output, solid protection features, and flexible mounting options make this switch reliable for installations where both data and power delivery over Ethernet are required. Performance is maintained even under load, and simplicity of deployment is ensured by its unmanaged design.
