HP LaserJet MFP M236sdw Printer - 9YG09A

Fastest in-class two-sided printing speed

Speed through multipage documents with the fastest in-class two-sided printing speed.

Small size. Big performance.

A LaserJet so compact it can fit almost anywhere.

Your reliable connection

Get better range and faster, more reliable connections using dual-band Wi-Fi™ with self-reset.

Increase productivity

Breeze through tasks with automatic scanning and copying.

Seamless setup

Get started fast with simple setup that guides you through each step, with HP Smart app.

Amazing scanning, now on your smartphone

Get high-quality scanning, and share to Dropbox, Google Drive, email, or the cloud – from virtually anywhere.

Printing just got more productive

Quickly access and print documents and images on your smartphone, from Dropbox and Google Drive.

Legendary laser quality

This surprisingly small laser delivers exceptional quality, page after page.

Smart-guided buttons

Easily manage tasks with smart-guided buttons for an intuitive experience – buttons appear only when needed.

Ready to help protect business

Get security essentials to help maintain privacy and control, including basic encryption and password protection.

On when you need it, off when you don’t

Help save energy with HP Auto-On/Auto-Off Technology – intelligence that can turn your printer on when you need it and off when you don’t.

Specifications

Print

• Print Speed, Black: 21 - 30
• Color Output: Black and white

Category

• Product Types: Laser printers
• Family Brand: LaserJet

Usage

• Perfect For: Home Recommended Usage: Everyday productivity, Home and home office

Features

• Functions: Print scan and copy

Media Handling

• Paper Size: A4, Legal, Letter

Connection And Communication

• Connectivity: Apple AirPrint™, Ethernet networking, Mopria™, USB, Wireless (Wi-Fi®), Wireless direct printing

Printing Media Handling

• Envelope Input Capacity: Up to 10 envelopes
• Output Capacity: Up to 100 sheets
• Maximum Output Capacity (Sheets): Up to 100 sheets
• Media Type And Capacity, Tray 1: Sheets: 150; Envelopes: 10
• Paper Handling Input, Standard: 150-sheet input tray
• Input Capacity: Up to 150 sheets
• Paper Handling Output, Standard: 100-sheet output tray
• Standard Output Capacity (Envelopes): Up to 10 envelopes
• Maximum Input Capacity (Sheets): Up to 150 sheets

Display Specifications

• Display: 6" Icon LCD
• Display Area (Metric): 5 x 33 mm
• Display Area (Imperial): 4 x 1.3 in

Environmental

• Acoustic Power Note: Configuration tested: simplex printing, A4 paper at an average of 29 ppm
• Acoustic Pressure Emissions Bystander (Active, Printing): 51 dB(A)
• Acoustic Pressure Emissions Bystander (Active Scan): 45 dB(A)
• Non-Operating Humidity Range: 10 to 90% RH
• Operating Humidity Range: 10 to 80% RH
• Storage Temperature Range: -20 to 60°C
• Operating Temperature Range: 15 to 32.5ºC
• Acoustic Power Emissions: 6 B(A)
• Recommended Operating Temperature Range: 5 to 25ºC
• Acoustic Power Emissions (Ready): 6 B(A)
• Acoustic Pressure Emissions Bystander (Ready): 16 dB(A)

Scan Speed

• Scan Speed (Normal, Letter): Up to 20 ppm (b&w), up to 11 ppm (color)
• Scan Speed (Normal, A4): Up to 19 ppm (b&w), up to 10 ppm (color)

Cartridges And Printheads

• Technology: Laser
• Number Of Print Cartridges: 1 (black)
• Replacement Cartridges: Regular Replacement Cartridge for DM1: HP 134A Black LaserJet Toner Cartridge, W1340A (~1100), HP 134X Black LaserJet Toner Cartridge, W1340X (~2400); Regular Replacement Cartridge for DM2: HP 135A Black LaserJet Toner Cartridge, W1350A (~1100), HP 135X Black LaserJet Toner Cartridge, W1350X (~2400); Regular Replacement Cartridge for RoEM: HP 136A Black LaserJet Toner Cartridge, W1360A (~1150), HP 136X Black LaserJet Toner Cartridge, W1360X (~2600); Regular Replacement Cartridge for China & India: HP 137A Black LaserJet Toner Cartridge, W1370A (~1150), HP 137X Black LaserJet Toner Cartridge, W1370X (~2600)
• Supplies Feature: HP JetIntelligence Cartridge

Copy Speed

• Copy Speed (Black, Normal Quality, A4): Up to 29 cpm
• Copy Speed Black (Normal, Letter): Up to 30 cpm
• Copy Speed Black Duplex (A4): Up to 18 cpm
• Copy Speed Black Duplex (Letter): Up to 19 cpm

Battery And Power

• Power: 220-volt input voltage: 220 to 240 VAC (+/- 10%), 60 Hz/50 Hz, 2.8 A
• Power Consumption Description: 453 watts (active printing), 3.3 watts (ready), 0.6 watts (sleep), 0.6 watts (Auto Off/Wake on LAN, enabled at shipment), 0.04 watts (Auto-off/Manual-on), 0.04 (Manual Off)
• Power Supply Type: Built-in 200V Power Supply

Print Time

• First Page Out Black (Letter, Ready): As fast as 6.9 sec
• First Page Out Black (A4, Ready): As fast as 7 sec
• First Page Out Color (A4, Ready): No
• First Page Out Black (Letter, Sleep): As fast as 7.5 sec
• First Page Out Black (A4, Sleep): As fast as 7.6 sec

Printer Specifications

• Duty Cycle (Monthly, Letter): Up to 20,000 pages
• Duty Cycle Note: Duty cycle is defined as the maximum number of pages per month of imaged output. This value provides a comparison of product robustness in relation to other HP LaserJet or HP Color LaserJet devices, and enables appropriate deployment of printers and MFPs to satisfy the demands of connected individuals or groups.
• Envelope Feeder: NA
• Recommended Monthly Page Volume Note: HP recommends that the number of printed pages per month be within the stated range for optimum device performance, based on factors including supplies replacement intervals and device life over an extended warranty period.
• Functions: Print, copy, scan
• Internal Storage: No
• Print Languages: PCLmS; URF; PWG
• Paper Trays, Maximum: 1
• Duty Cycle (Monthly, A4): Up to 20,000 pages
• Paper Trays, Standard: 1
• Recommended Monthly Page Volume: 20000
• Print Technology: Laser
• Duplex Printing: Auto-duplex
• Warm-Up Time: As fast as 45 sec
• Automatic Paper Sensor: Yes
• Printer Management: HP Printer Assistant (UDC); HP Device Toolbox
• Memory Card Compatibility: No
• Print Colours: No
• Top Key Features: Scan to email; Scan to PDF; Compact Size; Energy Efficient; Fast 2 sided printing; 40-sheet ADF; Dualband Wi-Fi
• Target User And Print Volume: For teams up to 5 users; Prints up to 20,000 pages/month

Scanner Specifications

• Scan Size (ADF), Maximum: 216 x 356 mm
• Scan File Format: JPEG, TIF, PDF, BMP, PNG
• Color Scanning: Yes
• Auto Document Feeder Capacity: Standard, 40 sheets
• Scanner Type: Flatbed, ADF
• Scan Size, Maximum: 216 x 297 mm
• Levels Of Grayscale: 256
• Scan Input Modes: HP Smart App; and user applications via Twain
• Scan Size ADF (Minimum): 148 x 210 mm
• Bit Depth: 24-bit
• Twain Version: Version 2.1
• Duplex ADF Scanning: No
• Recommended Monthly Scan Volume: 150 to 1500
• Software Scan File Format: JPEG, RAW(BMP), PNG, TIFF, PDF
• Native Scan File Format: JPG; PDF
• Scan Size, Maximum: 5 x 11.7 in
• Scan Size (ADF), Maximum: 5 x 14 in
• Scan Size ADF (Minimum): 8 x 8.3 in

Box Contents

• What's In The Box: HP LaserJet MFP M234sdw Printer; HP Black LaserJet Toner Cartridge (~700 pages); Reference Guide; Setup Poster; Warranty Guide & Flyer in some countries; CD-ROM containing software driver & electronic documentation; Power cord; USB cable
• Cable Included: Yes, 1 USB cable for all regions

Memory

• Memory Slots: No
• Memory Upgrade: No
• Memory: 64 MB
• Memory, Maximum: 64 MB

Dimensions

• Dimensions Without Stand (W X D X H): 0 x 308.0 x 294.4 mm
• Maximum Dimensions (W X D X H): 0 x 467.6 x 452.8 mm
• Minimum Dimensions (W X D X H): 46 x 12.13 x 11.59 in

Weights

• Weight: 5 kg

Certification And Compliance

• Energy Efficiency Compliance: EPEAT® Silver
• Electromagnetic Emission Standard: CISPR32:2012 & CISPR32:2015 /EN55032:2012 & EN55032:2015+AC:2016 - Class B; EN 61000-3-2:2014; EN 61000-3-3:2013; EN 55035:2017; FCC Title 47 CFR, Part 15 Class B/ICES-003, Issue 6.
• Safety Approvals And Requirements: EN 60950-1:2006 +A11:2009 +A1:2010 +A12:2011+A2:2013; IEC 60950-1:2005 +A1:2009+A2:2013; IEC/EN 62368-1:2014; CAN/CSA C22.2 No. 62368-1, 3rd Edition; UL62368-1, 3rd Edition; IEC/EN 60825-1 3rd Edition; EN 62479:2010 / IEC 62479:2010
• Telecom Compliance (Fax Capability): Wireless: EU RED 2014/53/EU; EN 301 489-1 V2.2.3 / EN 301 489-17: V3.2.0; EN 300 328: V2.1.1 / EN301 893 V2.1.1; FCC Title 47 CFR, Part 15 Subpart C & E / RSS 247 Issue 1, 2015 & RSS 102 Issue 5, 2015; IEC 62311:2007 / EN62311:2008
• Environmental: Mercury free
• Certifications And Compliances: RCM (Australia), TUV and GS Mark (Germany), BSMI (Taiwan), CCC (China), BIS (India), KC (South Korea), Malaysia, Cambodia, Ukraine, EAC, Eastern European approvals, CE Marking, FCC, Energy Star, UL, Paraguay, Indonesia, Singapore, Philippines, etc.

Geographic

• Country Of Origin: Made in Vietnam

Connectivity And Communications

• Connectivity, Standard: 1 Hi-Speed USB 2.0; 1 Fast Ethernet 10/100Base-TX; 1 Dual-band (2.4/5.0GHz) Wireless 802.11b/g/n with Bluetooth® Low Energy
• Network Capabilities: 1 Ethernet 10/100Base-TX; 1 built-in Wi-Fi 802.11b/g/n
• Wireless Capability: 1 built-in Wi-Fi 802.11b/g/n
• Mobile Printing Capability: Apple AirPrint™; HP Smart App; Mopria™ Certified; Wi-Fi® Direct Printing
• Network Protocols, Supported: TCP/IP: IPv4; IPv6; LPD; SLP; Bonjour; WS-Discovery; BOOTP/DHCP/AutoIP; SNMP v 1/2/3;HTTP/HTTPS; UDP; IPP

Fax Specifications

• Faxing: No

System Components

• Control Panel: Icon LCD; 5 lights (Status, Media, Attention, Toner, Lid open); 10 buttons (Power, Info, Wi-Fi, Resume, Cancel, Plus, Menu, Minus, Copy, ID copy)

Processors

• Processor Speed: 500 MHz

Scan Resolution

• Scan Resolution, Hardware: 600 x 1200 dpi
• Scan Resolution, Optical: Up to 600 dpi

Supported Printing Media

• Media Sizes Supported: A4; A5; A6; B5 (JIS)
• Media Size, Tray 1: A4; A5; A6; B5 (JIS)
• Standard Media Sizes (Duplex): A4
• Media Weight, Supported: 60 to 163 g/m²
• Media Types: Paper (laser, plain, rough, vellum), Envelopes, Labels, Cardstock, Postcard
• Recommended Media Weight (Duplex): 60 to 105 g/m²
• Media Weight (Tray 1): 60 to 163 g/m²
• Media Weights, Supported, ADF: 60 to 90 g/m²
• Media Sizes, Custom: 6 x 152.4 to 216 x 356 mm
• Media Sizes Supported, Key: 4 x 6 in; Letter; Legal; Envelopes
• Media Sizes Supported, Key: 10 x 15 cm; A4; Envelopes
• Media Size (ADF): A4, A5, B4, B5, Letter, Legal
• Media Weight, Supported: 16 to 43 lb
• Standard Media Sizes (Duplex, Imperial): Letter
• Media Sizes Supported: Letter, Legal, Executive, Envelopes
• Media Weights, Supported ADF: 16 to 24 lb
• Media Sizes, Custom: 4 x 6 to 8.5 x 14 in
• System Requirements: Minimum System Requirements For Macintosh: Apple® macOS v10.14 Mojave, macOS v10.15 Catalina, macOS v11 Big Sur; 2 GB HD; Internet required
• Minimum System Requirements: Microsoft® Windows® 10, 8.1, 8, 7: 32-bit or 64-bit, 2 GB available hard disk space, Internet connection, Microsoft® Internet Explorer.
• Software And Applications
• Driver Updates: hp.com
• Downloadable Software: From 123.hp.com: HP Smart for Windows 10, Mac, Mobile (Android and iOS); From hp.com: Full-solution software and drivers (with installer) and HP Easy Start; Product Documentation and Support; HP Print and Scan Doctor; From Mobile OS: See "HP Mobile Printing" (www.hp.com/go/mobileprinting); From In-OS app stores: HP Smart; HP Print Service Plugin; From hp.com for printer administrators: Linux Print Drivers; HP Web JetAdmin Software (HP SNMP Proxy Agent); ReadIris Software
• Mac Compatible: Yes
• Software Included: No CD inbox (expect Indonesia and China Gov); Downloadable Software from hp.com or 123.hp.com; #CD include HP Software Installer, Uninstaller, printer driver and other essential tools

Supported Operating Systems

• Compatible Operating Systems: Microsoft® Windows® 10, 8.1, 8, 7: 32-bit or 64-bit, 2 GB available hard disk space, Internet connection, USB port, Microsoft® Internet Explorer. Apple® macOS v10.14 Mojave, macOS v10.15 Catalina, macOS v11 Big Sur; 2 GB HD; Internet required; USB; Linux (For more information, see https://developers.hp.com/hp-linux-imaging-and-printing)
• Compatible Network Operating Systems: Windows Server 2008 R2 64-bit, Windows Server 2008 R2 64-bit (SP1), Windows Server 2012 64-bit, Windows Server 2012 R2 64-bit, Windows Server 2016 64-bit; Linux (For more information see http://developers.hp.com/hp-linux-imaging-and-printing)
• Operating System (Supported Note): Not supporting Windows® XP (64-bit) and Windows Vista® (64-bit) Full solution software available only for Windows 7 and newer; For Windows Server 2008 R2 64-bit, 2012 64-bit, 2012 R2 64-bit, 2016 64-bit only print driver is installed. Windows RT OS for Tablets (32 & 64-bit) uses a simplified HP print driver built into the RT OS; Linux systems use in-OS HPLIP software.

Print Resolution

• Print Quality Black (Normal): 600 x 400 dpi, 600 x 600 dpi
• Print Quality Black (Best): Up to 600 x 600 dpi

Rack And Power Specifications

• Typical Electricity Consumption (TEC) Number: 256 kWh/Week (Energy Star); 0.684 kWh/Week (Blue Angel)
• Number Of Users: 1-5 Users

Print Area

• Maximum Print Area: 216 x 354 mm
• Right Margin (A4): 5 mm
• Top Margin (A4): 6 mm
• Bottom Margin (A4): 6 mm
• Left Margin (A4): 5 mm

Advanced Features

• Printer Smart Software Features: Automatic duplex printing, HP Auto-On/Auto-Off[1], HP Smart App
• Energy Savings Feature Technology: HP Auto-on/Auto-off Technology

Copier Specifications

• Copies, Maximum: Up to 99 copies
• Copy Reduce / Enlarge Settings: 25 to 400%
• Copier Scaling (ADF): 25 to 400%
• Copier Settings: Reduce/Enlarge; Number of Copies; Lighter/Darker; Optimize; Paper size/type. It supports collation and single-sided on ADF bundles.

Security Management

• Security Management: Secure Boot, Secure Firmware Integrity, Runtime Code Integrity, password protected EWS, secure browsing via SSL/TLS 1.0, TLS 1.1, TLS 1.2; TLS 1.0/1.1 disabled by default; Update to OpenSSL version 1.1.1; enable/disable Network ports; SNMPv1, SNMPv2, and SNMPv3, community password change; Secure defaults, Encrypted data at rest, Active FW update, Admin password by default, Cipher & TLS selection; Account lockout; Secure Wi-Fi setup

Appearance

• Color: White
